Appendix3 SPECIAL RELAY LIST
*1 The relevant modules are as follows:
• The Universal model QCPU whose serial number (first five digits) is "10102" or later.
• Q00UJCPU, Q00UCPU, Q01UCPU
*2 1 minute clock indicates the name of the special relay (M9034) of the ACPU.
*3 The A8UPU/A8PUJ is not available for the QCPU/LCPU.
M9197 SM1197 ×
Switch between
blown fuse and
I/O module
verification error
display
Switches I/O numbers between the fuse-blown
module registers (SD1100 to SD1107) and I/O
module verify error registers (SD1116 to
SD1123) according to the on/off combination of
SM1197 and SM1198.
-
M9198 SM1198 ×
M9199 SM1199 ×
Data recovery of
online sampling
trace/status
latch
OFF : Data recovery
disabled
ON : Data recovery
enabled
• Recovers the setting data stored in the CPU
module at restart when sampling trace/status
latch is executed.
• Turn this on to re-execute the sampling trace
or status latch. (Rewriting data using the
programming tool is not required.)
ACPU
Special
Relay
Special
Relay after
Conversion
Special
Relay for
Modification
Name Meaning Details
Corres-ponding
CPU
OFF
ON
SM1197
OFF
SM1198
OFF
X/Y0 to 7F0
X/Y800 to FF0
OFF ON X/Y1000 to 17F0
ON ON X/Y1800 to 1FF0
I/O numbers
to be displayed
