5-11
ANB,ORB
1
2
3
4
5
6
7
8
5.2 Association Instructions
5.2.1 Ladder block series connection and parallel connection (ANB,ORB)
Operation Error
(1) There are no operation errors associated with ANB or ORB instruction.
Program Example
(1) A program using the ANB and ORB instructions.
[Ladder Mode] [List Mode]
Step
Instruction
Device
