5-39
PLS,PLF
1
2
3
4
5
6
7
8
5.3 Output Instructions
5.3.8 Leading edge and trailing edge outputs (PLS,PLF)
(2) The following program executes the PLF instruction when X9 goes OFF.
[Ladder Mode] [List Mode]
[Timing Chart]
Step
Instruction
Device
X9 OFF
M9 OFF
ON
ON
1 scan
