5.3 Output Instructions
5.3.9 Bit device output reverse (FF)
(2) The following program reverses b10 (bit 10) of D10 when X0 goes ON.
[Ladder Mode] [List Mode]
[Timing Chart]
Step
Instruction
Device
ON
X0
D10 of b10
OFF
0
10
