Mitsubishi MELSEC Q Series Programming Manual

5-60
NOP,NOPLF,PAGE n
• Printing the ladder will result in the following:
• Printing an instruction list with the NOPLF instruction will result in the following:
PAGE n
[Ladder Mode] [List Mode]
6 Y40
X1
END8
0
X0
D30MOV
K1
D40MOV K2
NOPLF
5
NOPLF instruction, inserted as a delimiter
of ladder blocks, causes print out page to
be changed forcibly.
LD
MOV
0
1
X0
K1 D30
MOV
NOPLF
3
5
K2 D40
LD
OUT
END
6
7
8
X1
Y40
Changes print output page
after printing NOPLF.
NOP
Step
Instruction
Device
