6-112
EDMOV(P)
Program Example
(1) The following program stores the 64-bit floating decimal point type real number at D10 to
D13 at D0 to D3.
[Ladder Mode] [List Mode]
[Operation]
(2) The following program stores the real number 1.23 at D10 to D13 when X8 is ON.
[Ladder Mode] [List Mode]
[Operation]
Step
Instruction
Device
D11
36.475
D10D13 D12
D1
36.475
D0D3 D2
Step
Instruction
Device
D11 D10D13 D12
