DIS(P)
Operation Error
(1) In any of the following cases, an operation error occurs, the error flag (SM0) turns ON, and
an error code is stored into SD0.
• The range n-points from exceeds the relevant device. (Error code: 4101)
• The value of n is outside the 0 to 4 range. (Error code: 4100)
Program Example
(1) The following program dissociates the 16-bit data from D0 into 4-bit groups, and stores from
D10 to D13 when X0 is ON.
[Ladder Mode] [List Mode]
[Operation]
D
Step
Instruction
Device
b15
0 0 0 0 0 0 0 0 0 0 0 000 0
1
b0
0 0 0 0 0 0 0 0 0 0 0 001 0 1
0 0 0 0 0 0 0 0 0 0 0 010 0 1
D10
b1b2b3b4
D11
D12
Storage area
b15
1 1
0 0
1
0 0
1
0
1
0
1
0 0 0
1
b8
D0
b7
b12 b11 b4 b3 b0
0 0 0 0 0 0 0 0 0 0 0 0
1
1
0 0
D13
Filled with 0s.
