FDEL(P),FINS(P)
Program Example
(1) The following program deletes the second data from the table R0 to R7 and stores the
deleted data at D0 when X10 is turned ON.
[Ladder Mode] [List Mode]
[Operation]
(2) The following program inserts the data at D0 into the third position at the table R0 to R7
when X10 is turned ON.
[Ladder Mode] [List Mode]
[Operation]
Step
Instruction
Device
R1
R2
R3
R4
Data table
-123
4444
5
3210
1234
0
4444
R5
5432
X10:ON
0 R6
R7
R0
R1
R2
R3
R4
Data table
-123
3210
4
1234
5432
0
R5
0
0 R6
R7
R0
D0
Data table
range
Data table
range
Step
Instruction
Device
R1
R2
R3
R4
Data table
1234
4444
4
-123
5000
0
-3210
R5 0
X10:ON
0 R6
R7
R0
R1
R2
R3
R4
Data table
1234
4444
5
-3210
-123
0
R5
0 R6
R7
R0
D0
Data table
range
5000
