7-388
DUTY
Program Example
(1) The following program turns SM420 ON for 1 scan, and OFF for 3 scans if X0 is ON.
[Ladder Mode] [List Mode]
[Operation]
Step Instruction Device
X0
3 scans1 scan
SM420
OFF
OFF
ON
ON
