RBMOV(P)
1
2
3
4
6
6
7
8
7.18 Other instructions 7.18.19 High-speed Block Transfer of File Register (RBMOV(P))
(2)Transfer from file registers to file registers
*1 : Unusable for the Q00UCPU and Q01UCPU.
CPU
Instruction
Target memory where
file register is stored
1 word 1000 words
10000 words
Min. Max. Min. Max. Min. Max.
QnHCPU
QnPHCPU
QnPRHCPU
RBMOV
Standard RAM
20.0 µs 91.0 µs 775.0 µs
SRAM card
22.5 µs 545.0 µs 5300.0 µs
BMOV
Standard RAM
7.5 µs 77.0 µs 720.0 µs
SRAM card
8.5 µs 692.0 µs 7050.0 µs
QnCPU
RBMOV
Standard RAM
45.5 µs 215.0 µs 1850.0 µs
SRAM card
50.0 µs 870.0 µs 8350.0 µs
BMOV
Standard RAM
17.5 µs 179.0 µs 1700.0 µs
SRAM card
18.5 µs 839.0 µs 8600.0 µs
Q00UCPU
Q01UCPU
RBMOV
Standard RAM
12.6 µs 35.3 µs 232.5 µs 256.1 µs 2211.5 µs 2235.1 µs
SRAM card*2
------
BMOV
Standard RAM
7.7 µs 14.2 µs 227.5 µs 234.2 µs 2206.5 µs 2214.2 µs
SRAM card*2
------
Q02UCPU
RBMOV
Standard RAM
9.6 µs 31.5 µs 228.5 µs 252.3 µs 2208.5 µs 2231.3 µs
SRAM card
9.6 µs 31.5 µs 378.5 µs 401.3 µs 3708.5 µs 3731.3 µs
BMOV
Standard RAM
5.2 µs 11.8 µs 224.5 µs 232.3 µs 2204.5 µs 2212.3 µs
SRAM card
5.2 µs 11.8 µs 374.5 µs 382.3 µs 3704.5 µs 3712.3 µs
Q03UD(E)CPU
RBMOV
Standard RAM
11.2 µs 16.7 µs 230.7 µs 237.1 µs 2210.7 µs 2217.1 µs
SRAM card
11.6 µs 16.7 µs 380.7 µs 387.1 µs 3710.7 µs 3717.1 µs
BMOV
Standard RAM
4.9 µs 6.7 µs 224.7 µs 227.1 µs 2204.7 µs 2207.1 µs
SRAM card
5.2 µs 6.7 µs 374.7 µs 377.1 µs 3704.7 µs 3707.1 µs
Q04UD(E)HCPU
Q06UDE(H)CPU
Q10UDE(H)CPU
Q13UDE(H)CPU
Q20UDE(H)CPU
Q26UDE(H)CPU
RBMOV
Standard RAM
9.3 µs 15.5 µs 118.0 µs 124.6 µs 1102.0 µs 1107.6 µs
SRAM card
9.7 µs 15.5 µs 365.0 µs 371.6 µs 3571.0 µs 3578.6 µs
BMOV
Standard RAM
4.3 µs 6.2 µs 113.0 µs 115.6 µs 1096.0 µs 1098.6 µs
SRAM card
4.5 µs 6.1 µs 360.0 µs 362.6 µs 3566.0 µs 3568.6 µs
