8.2 Reading/Writing Routing Information 8.2.1 Reading routing information (S(P).RTREAD)
Program Example
(1) The following program reads the routing information for the network number specified by D0
when X0 is turned ON.
[Ladder Mode] [List Mode]
[Operation] [Content of routing parameter setting]
Instruction
Device
Step
Transfer
destination
network number
Relay network
number
Relay station
number
1
2
3
10
10
10
3
2
1
10
3
Dummy
1
D1
D2
D3
D0
