Mitsubishi MELSEC Q Series Programming Manual

8-9
RTWRITE
1
2
3
4
6
6
7
8
8.2 Reading/Writing Routing Information 8.2.2 Registering routing information (S(P).RTWRITE)
Program Example
(1) The following program writes the routing information specified by D1 to D3 to the network
module of the network number specified by D0 when X0 is turned ON.
[Ladder Mode] [List Mode]
[Operation] [Content of routing parameter setting]
Instruction
Device
Step
Transfer
destination
network number
Relay network
number
Relay station
number
1
2
3
20
10
10
1
2
1
20
1
Dummy
1
D1
D2
D3
D0
