12-14
1401
[SP. UNIT DOWN]
• There was no response from the intelligent
function module/special function module in the
initial processing.
• The size of the buffer memory of the intelligent
function module/special function module is
invalid.
• The unsupported module is mounted.
â– Collateral information
• Common Information: Module No. (Slot No.)
• Individual Information:-
â– Diagnostic Timing
• At power-on/At reset/When intelligent function
module is accessed
When the unsupported module is mounted,
remove it.
If the corresponding module is supported, this
suggests the intelligent function module/special
function module, CPU module and/or base unit is
expecting a hardware fault (Please consult your
local Mitsubishi representative, explaining a
detailed description of the problem.)
RUN:
Off/On
ERR.:
Flicker/On
CPU Status:
Stop/
Continue
*6
QCPU
[SP. UNIT DOWN]
• There was no response from the intelligent
function module in the initial processing.
• The buffer memory size of the intelligent function
module is invalid.
• There was no response form the intelligent
function module.
• The start I/O No. of the targeted intelligent
function module is stored as a common
information upon error.
â– Collateral information
• Common information: Module No. (Slot No.)
• Individual Information:-
â– Diagnostic Timing
• At power-on/At reset/When intelligent function
module is accessed
• Reset the CPU module and run it again. If the
same error code is displayed again, the cause is
a hardware failure of the CPU module, I/O
module, intelligent function module, or END
cover.(Please consult your local Mitsubishi
representative, explaining a detailed description
of the problem.)
LCPU
1402
[SP. UNIT DOWN]
The intelligent function module/special function
module was accessed in the program, but there
was no response.
â– Collateral information
• Common Information: Module No. (Slot No.)
• Individual Information: Program error location
â– Diagnostic Timing
• When an intelligent function module access
instruction is executed
The cause is a hardware failure of the intelligent
function module/special function module, CPU
module, or base unit. (Please consult your local
Mitsubishi representative, explaining a detailed
description of the problem.)
QCPU
[SP. UNIT DOWN]
The intelligent function module was accessed by
the program, but there was no response.
â– Collateral information
• Common information: Module No. (Slot No.)
• Individual information: Program error location
â– Diagnostic Timing
• When an intelligent function module access
instruction is executed
• Reset the CPU module and run it again. If the
same error code is displayed again, the cause is
a hardware failure of the CPU module, I/O
module, intelligent function module, or END
cover. (Please consult your local Mitsubishi
representative, explaining a detailed description
of the problem.)
LCPU
Error
Code
Error Contents and Cause Corrective Action
LED Status
CPU Status
Corresponding
CPU
To Next Page
