2. Turn the cap (B) anticlockwise to re-
move it.
*: Front of the vehicle
3. Turn the socket (C) anticlockwise to re-
move it, and then pull the bulb out of the
socket.
4. To install the bulb, perform the removal
steps in reverse.
NOTE
l
When installing the bulb, align the tab (D)
with the notch (E) of the socket.
Headlamps (high-beam, halo-
gen bulb)
E01009401376
1. When replacing the bulb on the right
side of the vehicle, remove the clip (A)
holding down the washer tank spout and
then move it.
*: Front of the vehicle
2. Turn the cap (B) anticlockwise to re-
move it.
*: Front of the vehicle
Replacement of lamp bulbs
11-27
OGGE19E1
Maintenance
11
