8 - 39 8 - 39
MELSEC-Q
8 UTILITY PACKAGE (GX Configurator-SC)
8.6.4 MC protocol monitor
[Purpose]
Monitor the status and setting values of the data communication using the MC
protocol.
[Startup procedure]
[Monitor] screen CH MC protocol monitor
[Monitor screen]
