8 - 49 8 - 49
MELSEC-Q
8 UTILITY PACKAGE (GX Configurator-SC)
8.6.10 Display LED off and communication error information/error code initialization
This section explains how to turn off the display LEDs of the Q series C24 and initialize
its communication error information and error codes.
(1) CH ERR. clear request on Monitor/Test screen
This is used to turn off the CH ERR. LED of the Q series C24 and to initialize
(clear) the error codes stored in the CH
side buffer memory.
Refer to Section 10.1.2 (1) for the buffer memory where the error codes are
stored.
[Operation procedure]
1) Display the "Monitor/Test" screen.
2) Select "Clear request" for "CH
ERR. clear request".
3) Click on Execute test
.
To Next Page
