MELSEC-Q
2 SYSTEM CONFIGURATION AND AVAILABLE FUNCTIONS
2.4 For Use with Q00J/Q00/Q01CPU
This section describes the use of the Q series C24 with the Q00J/Q00/Q01CPU.
(1) Available functions
The following table indicates the functions that can be used when the Q series
C24 is mounted in the Q00J/Q00/Q01CPU.
Function Availability
Communications using the MC protocol (
1
)
Communications using non procedure protocol
Data reception by interrupt program
(
2
)
Communications using the bidirectional protocol
Data reception by interrupt program
(
2
)
Communications using dedicated instructions
Communications via public line, etc. (modem function)
Remote password check
(
2
)
DC code control (including Xon/Xoff control)
Transmission
Control
DTR/DSR (ER/DR) control
Communications protocol switching
Independent/linked operation of each interface
Initial setting and monitoring/testing of setting values by the utility package
Connecting the GX Developer and GOT
: Available : Not available
1 Communications are according to the MC protocol. See the Reference Manual concerning the
number of devices that can be accessed and the processing time.
The range of devices that can be accessed differs depending on the frame used in data
communications.
2 Use Q00J/Q00/Q01CPU (function version B) or later.
When using the function, version 8 or later of the GX Developer is required.
