MELSEC-Q
8 UTILITY PACKAGE (GX Configurator-SC)
8.6.5 Non procedure monitor/test
[Purpose]
Monitor the status and setting values of the data transmission using the non
procedure protocol. The test operation for the receive data clear is explained in
Section 8.7.
[Startup procedure]
[Monitor] screen CH Non procedure monitor/test
[Monitor/test screen]
