App. - 44 App. - 44
MELSEC-Q
APPENDIX
(c) Buffer memory settings used in this example
Address Decimal (Hexadecimal)
CH1
Name
Setting
value
150 (96
H
) Word/byte units designation Byte units
162 (A2
H
) Transmission buffer memory head address designation 0400
H
163 (A3
H
) Transmission buffer memory length designation 0200
H
183 (B7
H
) CR/LF output designation 0
184 (B8
H
) Output head pointer designation 1
185 (B9
H
) Output count designation 5
186 (BA
H
) First output frame No. designation 03F2
H
187 (BB
H
) Second output frame No. designation 03F3
H
188 (BC
H
) Third output frame No. designation 8001
H
189 (BD
H
) Fourth output frame No. designation 8000
H
190 (BE
H
) Fifth output frame No. designation 041B
H
6912 (1B00
H
) Registered data byte count designation 2
6913 (1B01
H
)
For registration
No. 8001
H
User frame storage 012D
H
To Next Page
