Mitsubishi QJ71C24/-R2 User Manual

1 - 11 1 - 11
MELSEC-Q
1 OVERVIEW
Function
QJ71C24N
(-R2/R4)
QJ71C24
(-R2)
Outline of function Reference section
Multiple specification of
transparent codes for
transmission
This function allows specification of a maximum of 10 types of transparent
codes for transmission per interface when sending data using one of the
following protocols:
• Non procedure protocol
• Bidirectional protocol
Chapter 12 of
User’s Manual
(Application)
Switching to the GX
Developer connection mode
by switching the mode
This functions allows the GX Developer connection mode to be switched by
an external device or the PLC CPU.
Chapter 15 of
User’s Manual
(Application)
Section 3.13 of
Reference Manual
Communication data
monitoring function
This function allows the monitoring of communication data transmitted on
the communication network of the Q series C24 and an external device.
Chapter 16 of
User’s Manual
(Application)
Operating Manual
(Protocol FB
support function)
UINI instruction
The UINI instruction allows change of the mode, transmission specifications
and host station No. of the Q series C24.
Chapter 17 of
User’s Manual
(Application)
Support for multiple CPU
system
This function allows access to the control/non-control PLCs specified by the
user when performing the following forms of data communication with a
multiple CPU system:
• Communication using the MC protocol
• QCPU access from GX Developer
Section 2.10 of
Reference Manual
