2 - 11 2 - 11
MELSEC-Q
2 SYSTEM CONFIGURATION AND AVAILABLE FUNCTIONS
(3) Setting from GX Developer
The following parameters should be set through GX Developer in order to use
the Q series C24 mounted to a MELECNET/H remote I/O station.
Each of setting is the same way as when setting the parameters for the Q series
C24 mounted to a QCPU station: see Section 4.5 and after.
See the operating manual for GX Developer for how to display each setting
screen.
(Parameter setting items for the Q series C24 mounted to a MELECNET/H
remote I/O station)
Parameter setting item Setting Remarks
I/O Assignment Set the module mounting information See Section 4.5.1
Switch setting for I/O and
intelligent function module
Set the transmission specification and the
communication protocol for communication
with the external device
See Section 4.5.2
Remote password setting Perform settings for the remote password.
User's Manual (Application)
Section 3.3.3
POINT
(1) Connect GX Developer to a MELECNET/H remote I/O station and set the
parameters.
(2) Reset the MELECNET/H remote I/O station after changing the setting.
(4) When monitoring/setting with GX Configurator-SC
(a) About the automatic refresh setting
1) When reading/writing data created by the automatic refresh setting
using PLC, the read/write operation should be performed by GX
Developer. It cannot be performed from GX Configurator-SC.
2) The devices used for the automatic refresh setting must be of the types
M, B, D, or W.
POINT
(1) GX Configurator-SC should be connected to a MELECNET/H remote I/O
station before the monitoring/setting.
(2) The MELECNET/H remote I/O station should be reset after changing the
setting.
