8 SPECIFICATIONS OF CONNECTOR/TERMINAL BLOCK CONVERTER
MODULES
8. SPECIFICATIONS OF CONNECTOR/TERMINAL BLOCK CONVERTER
MODULES
8.1 Specifications of Connector/Terminal Block Converter Modules
This chapter explains the specifications of connector/terminal block converter modules.
(1) Connector/terminal block converter module
Type Details Weight
Applicable
wire size
Applicable
crimping
terminal
Applicable Models
A6TBXY36
For positive common type input
modules and sink type output
modules (standard type)
0.4kg
0.75
to
2mm
2
1.25-3.5(JIS)
1.25-YS3A
V1.25-M3
V1.25-YS3A
2-3.5(JIS)
2-YS3A
V2-S3
V2-YS3A
Q series QX41, QX41-S1, QX41-S2, QX42,
QX42-S1, QY41H, QY41P, QY42P,
QY82P, QH42P, QX41Y41P
AnS series A1SX41, A1SX41-S1, A1SX41-S2,
A1SX42, A1SX42-S1, A1SX42-S2,
A1SX82-S1, A1SY41, A1SY41P,
A1SY42, A1SY42P, A1SY82, A1SH42,
A1SH42P, A1SH42-S1, A1SH42P-S1
A series AX42, AX42-S1, AY42, AY42-S1,
AY42-S3, AY42-S4, AH42
CC-Link AJ65SBTCF1-32D, AJ65SBTCF1-32T,
AJ65BTC1-32D, AJ65BTC1-32T
MELSECNET-MINI AJ35TC1-32D, AJ35TC1-32T
A6TBXY54
For positive common type input
modules and sink type output
modules (2-wire type)
0.5kg
A6TBX70
For positive common type input
modules
(3-wire type)
0.6kg
Q series QX41, QX41-S1, QX41-S2, QX42,
QX42-S1, QH42P, QX41Y41P
AnS series A1SX41, A1SX41-S1, A1SX41-S2,
A1SX42, A1SX42-S1, A1SX42-S2,
A1SX82-S1, A1SH42, A1SH42P,
A1SH42-S1, A1SH42P-S1
A series AX42, AX42-S1, AH42
CC-Link AJ65SBTCF1-32D, AJ65BTC1-32D
MELSECNET-MINI AJ35TC1-32D
A6TBX36-E
For negative common type input
modules (standard type)
0.4kg
Q series QX81, QX81-S2
AnS series A1SX81, A1SX81-S2
A series AX82
A6TBX54-E
For negative common type input
modules (2-wire type)
0.5kg
A6TBX70-E
For negative common type input
modules (3-wire type)
0.6kg
A6TBY36-E
For source type output modules
(standard type)
0.4kg
Q series QY81P
AnS series A1SY81
A series AY82EP
A6TBY54-E
For source type output modules
(2-wire type)
0.5kg
