Mitsubishi VL-100EU5-E User Manual

Eng-5
English
Note
- Check that each air supply/exhaust pipe
A catches on all four prongs of its pipe
mounting plate. (If a prong has not caught,
the pipe will press against the back of
the Lossnay unit and the shutter may not
operate properly.)
4)Ifthewallismorethan300mmthick
Cutairsupply/exhaustpipesBinkeepingwith
thecuttingdimensionsofstep2(wallthickness
+30to40mm).
Note
- Securely screw air supply/exhaust pipes A
and B together all the way.(If they are not
screwed together tightly, water inltration
may occur.)
- Caulk the connections between air supply/
exhaust pipes A and B as shown above.
Attaching the mounting plate
1)Attachthemountingplatetothewall
provisionally using a single loosely attached
screw.
2) Hang a plumb bob to make sure that the
looselyattachedmountingplateishorizontal
(towithin1°).
3) Attach eight wood screws at locations where
thewallcontainsreinforcingmaterial.
Note
- Attach the two locations near the catches
underneath the catches.(See diagram above.)
- To attach the plate to a concrete wall, use off-
the-shelf concrete screws.
Air supply/
exhaustpipeB
Air supply/exhaust
pipeB
Air supply/
exhaust pipe A
Air supply/exhaust pipe A
Caulking
Caulking
Catch
Attach under
the catches
Mounting plate
Plumb bobWood screw
Wood screw (loosely attached screw)
Catch
Cutting air supply/exhaust pipes
1)Measurethewallthickness.
(Ifthewallismorethan300mmthick,use
theprovidedairsupply/exhaustpipeB).(See
page4,section4,formountinginstructions.)
2) Cut air supply/exhaust pipes A perpendicular
to the pipe axis at the length shown in the
gureabove.
- Ifthepipeislongerthanitisshown,the
weathercoverwillnott.
3) Prepare the air supply/exhaust pipes.
- Insert each air supply/exhaust pipe A
into a pipe mounting plate and rotate it
counterclockwiseuntilthefourprongscatch.
Caution
- Mount air supply/exhaust pipes A so that
the UNDER mark is at the bottom. After
mounting the pipes, check that they slope
downward as they go outside. (If they do
not, rainwater may inltrate the wall and the
shutter may not operate properly.)
Cut perpendicular to the
pipe
Wall
thickness
OutsideInside
(Dimensionattopofpipe)
90°
Cut length
Air supply/
exhaust pipe A
Cut on this side
30to40mm
Air supply/exhaust
pipe A
Pipe mounting
plate
Beforesettinginplace
UNDERmark UNDERmark
Aftersettinginplace
Prong
Air supply/exhaust
pipe A
