Mitsubishi XL1XU Service Manual

L2C5 325C240O70 CHIP COIL 3.3µH-M
L2C6 325C240O70 CHIP COIL 3.3µH-M
L2C7 325C241O70 CHIP COIL 22µH-K
L386 325C241O70 CHIP COIL 22µH-K
L5A0 325C241O30 CHIP COIL 10µH-K
L602 325C241O30 CHIP COIL 10µH-K
L603 325C241O70 CHIP COIL 22µH-K
L803 325C241O30 CHIP COIL 10µH-K
L8A3 325C241O30 CHIP COIL 10µH-K
L8M3 325C241O30 CHIP COIL 10µH-K
L904 321C142O60 RF COIL 120µH-K
! L905 351P201O30 CHOKE COIL SLF12565T-221M1R0
L907 321C142O90 RF COIL 220µH-K
L908 321C152O40 RF COIL 82µH-K
L952 321C142O40 RF COIL 82µH-K
! L9F0 351P079O10 CHOKE COIL SN12-500J
TRANSFORMERS
! T900 350P767O30 POWER TRANSFORMER DC-08068-22
! T950 350P768O10 POWER TRANSFORMER
RESISTORS
L200 103P509O50 CHIP RESISTOR 0Ω(RM1608)
L201 103P509O50 CHIP RESISTOR 0Ω(RM1608)
L202 103P509O50 CHIP RESISTOR 0Ω(RM1608)
L203 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
L204 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
L205 103P509O50 CHIP RESISTOR 0Ω(RM1608)
L206 103P509O50 CHIP RESISTOR 0Ω(RM1608)
L270 103P509O50 CHIP RESISTOR 0Ω(RM1608)
L271 103P509O50 CHIP RESISTOR 0Ω(RM1608)
L272 103P509O50 CHIP RESISTOR 0Ω(RM1608)
L273 103P509O50 CHIP RESISTOR 0Ω(RM1608)
L274 103P509O50 CHIP RESISTOR 0Ω(RM1608)
L3M0 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
L3M2 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
L7E1 103P490O80 CHIP METAL RESISTOR 1/16W 200Ω-F
L7F0 103P492O50 CHIP METAL RESISTOR 1/16W 1kΩ-F
L7F1 103P492O50 CHIP METAL RESISTOR 1/16W 1kΩ-F
L7F2 103P492O50 CHIP METAL RESISTOR 1/16W 1kΩ-F
L7G9 103P501O30 CHIP RESISTOR 1/16W 100Ω-J [X]
L7H3 103P509O50 CHIP RESISTOR 0Ω(RM1608)
L7H6 103P501O30 CHIP RESISTOR 1/16W 100Ω-J [X]
L7K9 103P509O50 CHIP RESISTOR 0Ω(RM1608) [X]
L7L0 103P509O50 CHIP RESISTOR 0Ω(RM1608) [X]
L7L4 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
L7L8 103P492O50 CHIP METAL RESISTOR 1/16W 1kΩ-F
L7L9 103P492O50 CHIP METAL RESISTOR 1/16W 1kΩ-F
R200 103P489O90 CHIP METAL RESISTOR 1/4W 75Ω-J
R201 103P489O90 CHIP METAL RESISTOR 1/4W 75Ω-J
R202 103P489O90 CHIP METAL RESISTOR 1/4W 75Ω-J
R203 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R204 103P500O90 CHIP RESISTOR 1/20W 47Ω-J
R205 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R206 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R207 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R208 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R209 103P500O80 CHIP RESISTOR 1/16W 39Ω-J
R210 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R211 103P500O90 CHIP RESISTOR 1/20W 47Ω-J
R212 103P504O10 CHIP RESISTOR 1/16W 22kΩ-J
R216 103P504O10 CHIP RESISTOR 1/16W 22kΩ-J
R220 103P501O70 CHIP RESISTOR 1/16W 220Ω-J
R221 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R222 103P504O50 CHIP RESISTOR 1/16W 47kΩ-J
R223 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R224 103P809O90 CHIP METAL RESISTOR 1W 75Ω-J
R225 103P501O70 CHIP RESISTOR 1/16W 220Ω-J
R230 103P501O70 CHIP RESISTOR 1/16W 220Ω-J
R234 103P809O90 CHIP METAL RESISTOR 1W 75Ω-J
R235 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R238 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R239 103P809O90 CHIP METAL RESISTOR 1W 75Ω-J
R240 103P502O70 CHIP RESISTOR 1/16W 1.5kΩ-J
R241 103P502O80 CHIP RESISTOR 1/16W 1.8kΩ-J
R242 103P502O60 CHIP RESISTOR 1/16W 1.2kΩ-J
R243 103P502O70 CHIP RESISTOR 1/16W 1.5kΩ-J
R244 103P502O80 CHIP RESISTOR 1/16W 1.8kΩ-J
R245 103P502O60 CHIP RESISTOR 1/16W 1.2kΩ-J
R246 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R247 103P481O30 CHIP METAL RESISTOR 1/4W 100Ω-J
R248 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R249 103P481O30 CHIP METAL RESISTOR 1/4W 100Ω-J
R251 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R252 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R255 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R256 103P504O50 CHIP RESISTOR 1/16W 47kΩ-J
R257 103P504O90 CHIP RESISTOR 1/16W 100kΩ-J
R2A0 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R2A1 103P490O50 CHIP METAL RESISTOR 1/16W 150Ω-F
R2A5 103P491O90 CHIP METAL RESISTOR 1/16W 560Ω-F
R2C1 103P490O50 CHIP METAL RESISTOR 1/16W 150Ω-F
R2C5 103P491O90 CHIP METAL RESISTOR 1/16W 560Ω-F
R2D1 103P490O50 CHIP METAL RESISTOR 1/16W 150Ω-F
R2D5 103P491O90 CHIP METAL RESISTOR 1/16W 560Ω-F
R2E0 103P500O90 CHIP RESISTOR 1/20W 47Ω-J
R2E3 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R2E4 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R2E5 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R2E6 103P503O30 CHIP RESISTOR 1/16W 4.7kΩ-J
R2E7 103P503O30 CHIP RESISTOR 1/16W 4.7kΩ-J
R2F0 103P503O10 CHIP RESISTOR 1/16W 3.3kΩ-J
R2F1 103P503O10 CHIP RESISTOR 1/16W 3.3kΩ-J
R2M0 103P489O90 CHIP METAL RESISTOR 1/4W 75Ω-J
R2M1 103P489O90 CHIP METAL RESISTOR 1/4W 75Ω-J
R2M2 103P489O90 CHIP METAL RESISTOR 1/4W 75Ω-J
R2M5 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R2M6 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R2M7 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R2N0 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R2N1 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R2N2 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R2N5 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
SYMBOL PA RTS
PARTS NAME DESCRIPTION
No. No.
SYMBOL PART S
PARTS NAME DESCRIPTION
No. No.
-
9 -
[S] : SL2U [X] : XL2U
