Mitsubishi XL1XU Service Manual

R2N6 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R380 103P494O90 CHIP METAL RESISTOR 1/16W 10kΩ-F
R381 103P494O90 CHIP METAL RESISTOR 1/16W 10kΩ-F
R382 103P494O90 CHIP METAL RESISTOR 1/16W 10kΩ-F
R384 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R385 103P495O90 CHIP METAL RESISTOR 1/16W 27kΩ-F
R386 103P495O90 CHIP METAL RESISTOR 1/16W 27kΩ-F
R388 103P494O90 CHIP METAL RESISTOR 1/16W 10kΩ-F
R389 103P495O70 CHIP METAL RESISTOR 1/16W 22kΩ-F
R391 103P495O70 CHIP METAL RESISTOR 1/16W 22kΩ-F
R3M0 103P505O50 CHIP RESISTOR 1/16W 330kΩ-J
R3M4 103P505O50 CHIP RESISTOR 1/16W 330kΩ-J
R400 103P500O10 CHIP RESISTOR 1/16W 10Ω-J
R401 103P500O10 CHIP RESISTOR 1/16W 10Ω-J
R402 103P500O10 CHIP RESISTOR 1/16W 10Ω-J
R440 103P490O80 CHIP METAL RESISTOR 1/16W 200Ω-F
R441 103P492O50 CHIP METAL RESISTOR 1/16W 1kΩ-F
R474 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R480 103P500O10 CHIP RESISTOR 1/16W 10Ω-J
R484 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R490 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R491 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R494 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R4B0 103P500O90 CHIP RESISTOR 1/20W 47Ω-J
R4G0 103P500O90 CHIP RESISTOR 1/20W 47Ω-J
R4R0 103P500O90 CHIP RESISTOR 1/20W 47Ω-J
R4T0 103P500O90 CHIP RESISTOR 1/20W 47Ω-J
R4T2 103P500O90 CHIP RESISTOR 1/20W 47Ω-J
R4T3 103P500O90 CHIP RESISTOR 1/20W 47Ω-J
R4W0 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R505 103P502O10 CHIP RESISTOR 1/16W 470Ω-J
R506 103P502O10 CHIP RESISTOR 1/16W 470Ω-J
R508 103P502O90 CHIP RESISTOR 1/16W 2.2kΩ-J
R513 103P506O10 CHIP RESISTOR 1/16W 1MΩ-J
R514 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R521 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R530 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R531 103P502O10 CHIP RESISTOR 1/16W 470Ω-J
R532 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R533 103P502O10 CHIP RESISTOR 1/16W 470Ω-J
R534 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R535 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R543 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R5B1 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R5B2 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R601 103P493O70 CHIP METAL RESISTOR 1/16W 3.3kΩ-F
R602 103P493O60 CHIP METAL RESISTOR 1/16W 3kΩ-F
R612 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R632 103P500O10 CHIP RESISTOR 1/16W 10Ω-J
R633 103P500O10 CHIP RESISTOR 1/16W 10Ω-J
R710 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R713 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R715 103P502O10 CHIP RESISTOR 1/16W 470Ω-J
R716 103P502O10 CHIP RESISTOR 1/16W 470Ω-J
R720 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R721 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R726 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R738 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R739 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R741 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R742 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R743 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R745 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R746 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R782 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R783 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R787 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R7A0 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R7A1 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R7A2 103P492O50 CHIP METAL RESISTOR 1/16W 1kΩ-F
R7B3 103P501O70 CHIP RESISTOR 1/16W 220Ω-J
R7C1 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R7C2 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R7C3 103P501O70 CHIP RESISTOR 1/16W 220Ω-J
R7C5 103P503O30 CHIP RESISTOR 1/16W 4.7kΩ-J
R7C6 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R7C7 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R7C8 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R7D0 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R7D1 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R7D8 103P498O30 CHIP METAL RESISTOR 1/16W 270kΩ-F
R7E5 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R7E6 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R7E8 103P493O70 CHIP METAL RESISTOR 1/16W 3.3kΩ-F
R7F1 103P494O30 CHIP METAL RESISTOR 1/16W 5.6kΩ-F
R7G1 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R7G9 103P506O10 CHIP RESISTOR 1/16W 1MΩ-J [X]
R7J0 103P504O10 CHIP RESISTOR 1/16W 22kΩ-J
R7J1 103P504O10 CHIP RESISTOR 1/16W 22kΩ-J
R7J2 103P504O10 CHIP RESISTOR 1/16W 22kΩ-J
R7J3 103P497O30 CHIP METAL RESISTOR 1/16W 100kΩ-F
R7J4 103P495O30 CHIP METAL RESISTOR 1/16W 15kΩ-F
R7J7 103P496O10 CHIP METAL RESISTOR 1/16W 33kΩ-F
R7J8 103P495O70 CHIP METAL RESISTOR 1/16W 22kΩ-F
R7J9 103P496O90 CHIP METAL RESISTOR 1/6W 68kΩ-F
R7K0 103P500O80 CHIP RESISTOR 1/16W 39Ω-J [X]
R7K1 103P500O80 CHIP RESISTOR 1/16W 39Ω-J [X]
R7K6 103P495O90 CHIP METAL RESISTOR 1/16W 27kΩ-F
R7K7 103P496O60 CHIP METAL RESISTOR 1/16W 51kΩ-F
R7K8 103P495O30 CHIP METAL RESISTOR 1/16W 15kΩ-F
R7L0 103P500O50 CHIP RESISTOR 1/16W 22Ω-J
R7L3 103P495O20 CHIP METAL RESISTOR 1/16W 13kΩ-F
R7L4 103P495O60 CHIP METAL RESISTOR 1/16W 20kΩ-F
R7L6 103P502O00 CHIP RESISTOR 1/16W 390Ω-J
R7L7 103P502O00 CHIP RESISTOR 1/16W 390Ω-J
R7L8 103P502O00 CHIP RESISTOR 1/16W 390Ω-J
R7L9 103P502O00 CHIP RESISTOR 1/16W 390Ω-J
R7M0 103P502O00 CHIP RESISTOR 1/16W 390Ω-J
R7M1 103P502O00 CHIP RESISTOR 1/16W 390Ω-J
R7M2 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R7M3 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R7M4 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R7M5 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R7M6 103P502O10 CHIP RESISTOR 1/16W 470Ω-J
SYMBOL PA RTS
PARTS NAME DESCRIPTION
No. No.
SYMBOL PART S
PARTS NAME DESCRIPTION
No. No.
-
10 -
[S] : SL2U [X] : XL2U
