Mitsubishi XL1XU Service Manual

R7M7 103P504O10 CHIP RESISTOR 1/16W 22kΩ-J
R7M8 103P504O10 CHIP RESISTOR 1/16W 22kΩ-J
R7M9 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R7N0 103P502O10 CHIP RESISTOR 1/16W 470Ω-J
R7N4 103P502O70 CHIP RESISTOR 1/16W 1.5kΩ-J [X]
R7N6 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J [X]
R7N9 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R7P0 103P503O70 CHIP RESISTOR 1/16W 10kΩ-J
R7P5 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R7P6 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R7P7 103P501O30 CHIP RESISTOR 1/16W 100Ω-J
R7P9 103P502O10 CHIP RESISTOR 1/16W 470Ω-J
R7Q0 103P502O50 CHIP RESISTOR 1/16W 1kΩ-J
R7Q1 103P501O70 CHIP RESISTOR 1/16W 220Ω-J
R7Q2 103P501O70 CHIP RESISTOR 1/16W 220Ω-J
R7U1 103P490O50 CHIP METAL RESISTOR 1/16W 150Ω-F
R7U2 103P490O50 CHIP METAL RESISTOR 1/16W 150Ω-F
R7W0 103P496O70 CHIP RESISTOR 1/16W 56kΩ-F
R7W1 103P493O30 CHIP METAL RESISTOR 1/16W 2.2kΩ-F
R822 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R824 103P500O10 CHIP RESISTOR 1/16W 10Ω-J
R825 103P500O10 CHIP RESISTOR 1/16W 10Ω-J
R827 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R840 103P504O50 CHIP RESISTOR 1/16W 47kΩ-J
R851 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R8C2 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R8C4 103P500O10 CHIP RESISTOR 1/16W 10Ω-J
R8C5 103P500O10 CHIP RESISTOR 1/16W 10Ω-J
R8C7 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R8E0 103P504O50 CHIP RESISTOR 1/16W 47kΩ-J
R8F1 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R8P2 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R8P4 103P500O10 CHIP RESISTOR 1/16W 10Ω-J
R8P5 103P500O10 CHIP RESISTOR 1/16W 10Ω-J
R8P7 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R8R0 103P504O50 CHIP RESISTOR 1/16W 47kΩ-J
R8S1 103P509O50 CHIP RESISTOR 0Ω(RM1608)
R900 103P478O50 CHIP RESISTOR 1/10W 330kΩ-F
R901 103P478O80 CHIP METAL RESISTOR 1/10W 430kΩ-F
R902 103P478O40 CHIP METAL RESISTOR 1/10W 300kΩ-F
R903 103P475O10 CHIP RESISTOR 1/10W 12kΩ-F
R904 103P480O10 CHIP METAL RESISTOR 1/4W 10Ω-J
R906 103P478O50 CHIP RESISTOR 1/10W 330kΩ-F
R907 103P478O50 CHIP RESISTOR 1/10W 330kΩ-F
R908 103P478O50 CHIP RESISTOR 1/10W 330kΩ-F
R909 103P478O50 CHIP RESISTOR 1/10W 330kΩ-F
R910 103P474O70 CHIP RESISTOR 1/10W 8.2kΩ-F
R911 103P478O40 CHIP METAL RESISTOR 1/10W 300kΩ-F
R912 103P471O30 CHIP RESISTOR 1/10W 330Ω-F
R916 103P474O90 CHIP RESISTOR 1/10W 10kΩ-F
R917 103P484O20 CHIP METAL RESISTOR 1/4W 27kΩ-J
R918 103P471O30 CHIP RESISTOR 1/10W 330Ω-F
R919 103P472O50 CHIP RESISTOR 1/10W 1kΩ-F
R920 103P472O50 CHIP RESISTOR 1/10W 1kΩ-F
R921 103P478O90 CHIP RESISTOR 1/10W 470kΩ-F
R922 103P475O70 CHIP RESISTOR 1/10W 22kΩ-F
R923 103P474O50 CHIP RESISTOR 1/10W 6.8kΩ-F
R924 103P473O30 CHIP RESISTOR 1/10W 2.2kΩ-F
R925 103P483O60 CHIP METAL RESISTOR 1/4W 8.2kΩ-J
R926 103P474O50 CHIP RESISTOR 1/10W 6.8kΩ-F
R927 103P476O50 CHIP RESISTOR 1/10W 47kΩ-F
R928 103P491O70 CHIP METAL RESISTOR 1/16W 470Ω-F
R932 103P495O40 CHIP METAL RESISTOR 1/16W 16kΩ-F
R936 103P492O50 CHIP METAL RESISTOR 1/16W 1kΩ-F
R937 103P498O20 CHIP METAL RESISTOR 1/16W 240kΩ-F
R938 103P495O10 CHIP METAL RESISTOR 1/16W 12kΩ-F
R939 103P496O50 CHIP METAL RESISTOR 1/16W 47kΩ-F
R940 103P496O50 CHIP METAL RESISTOR 1/16W 47kΩ-F
R941 103P472O50 CHIP RESISTOR 1/10W 1kΩ-F
R943 103P475O70 CHIP RESISTOR 1/10W 22kΩ-F
R951 103P409O00 CHIP METAL RESISTOR 1/10W 6.8Ω-J
R952 103P400O80 CHIP METAL RESISTOR 1/10W 39Ω-J
R953 103P494O90 CHIP METAL RESISTOR 1/16W 10kΩ-F
R954 103P494O90 CHIP METAL RESISTOR 1/16W 10kΩ-F
R955 103P401O10 CHIP RESISTOR 1/10W 68Ω-J
R956 103P489O50 CHIP METAL RESISTOR 1/4W 0Ω RM3225
R970 103P496O90 CHIP METAL RESISTOR 1/6W 68kΩ-F
R971 103P480O10 CHIP METAL RESISTOR 1/4W 10Ω-J
R972 103P409O50 CHIP RESISTOR 0.1W 0Ω(2125)
R973 103P482O80 CHIP METAL RESISTOR 1/4W 1.8kΩ-J
R974 103P482O70 CHIP METAL RESISTOR 1/4W 1.5kΩ-J
R9A1 103P473O20 CHIP RESISTOR 1/10W 2kΩ-F
R9A4 103P492O80 CHIP RESISTOR 1/16W 1.3kΩ-F
R9B1 103P473O20 CHIP RESISTOR 1/10W 2kΩ-F
R9B4 103P492O80 CHIP RESISTOR 1/16W 1.3kΩ-F
CAPACITORS AND TRIMMERS
C200 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C201 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C202 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C203 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C204 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C205 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C206 154P343O30 CHIP CAPACITOR CH50V 82pF-J
C208 154P344O10 CHIP CAPACITOR CH50V 180pF-J
C212 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C220 181P520O10 CHIP ELE CAPACITOR 6.3V 22µF-M
C221 141P144O60 CHIP CAPACITOR F16/10V 1µF-Z
C222 181P520O10 CHIP ELE CAPACITOR 6.3V 22µF-M
C223 141P144O60 CHIP CAPACITOR F16/10V 1µF-Z
C241 141P144O60 CHIP CAPACITOR F16/10V 1µF-Z
C242 181P520O30 CHIP ELE CAPACITOR 6.3V 4.7µF-M
C243 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C244 141P144O20 CHIP CAPACITOR F16V 0.1µF-Z
C245 154P343O50 CHIP CAPACITOR CH50V 100pF-J
C246 154P343O50 CHIP CAPACITOR CH50V 100pF-J
C281 141P144O60 CHIP CAPACITOR F16/10V 1µF-Z
C283 141P144O60 CHIP CAPACITOR F16/10V 1µF-Z
C285 181P520O10 CHIP ELE CAPACITOR 6.3V 22µF-M
C286 181P520O10 CHIP ELE CAPACITOR 6.3V 22µF-M
C287 141P144O60 CHIP CAPACITOR F16/10V 1µF-Z
C288 141P144O60 CHIP CAPACITOR F16/10V 1µF-Z
C2A0 141P142O90 CHIP CAPACITOR B25V/16V 0.047µF-K
SYMBOL PA RTS
PARTS NAME DESCRIPTION
No. No.
SYMBOL PART S
PARTS NAME DESCRIPTION
No. No.
-
11 -
[S] : SL2U [X] : XL2U
