1 INTRODUCTION
This chapter describes the outline of the data processing unit
“QM-Data”, and the name and function of each component.
1
1.1 Outline
This data processing unit “QM-Data” is used to process data from a manual
coordinate measuring machine (manual CMM).
In this data processing unit, measurement instructions, measurement values, and
various calculation results are displayed graphically on an LCD in a form that is easy to
understand.
Measurement results can be output using the receipt printer, which is a small thermal
printer (an optional accessory), or on a printer handling A4-size paper or continuous paper.
Created part programs, measured data, and measurement results can be stored on a
floppy disk (in this case, the optional floppy disk drive is necessary); the stored part programs,
measured data, and measurement results can then be used when necessary.
No. 99MCA081A
1-1
