5 SPECIFICATIONS
This chapter describes the specifications for the data processing unit
“QM-Data”, the standard accessories, and the optional accessories.
5
5.1 Basic Specifications
Item Specification
Monitor Graphic LCD (320 × 240 dots; with backlight)
Displayable languages Japanese / English / German / French / Italian / Spanish / Portuguese
Power supply AC adapter
Electric power consumption Max. 24 W (not including any optional accessories)
Dimensions 200 (W) × 90 (D) × 280 (H) mm
Mass 1.2 kg
Operating temperature range 10 ~ 30 °C
Operating humidity range 20 ~ 80 %RH (Must be free from condensation)
Storage temperature range -10 ~ 50 °C
Storage humidity range 5 ~ 90 %RH (Must be free from condensation)
TIP
Refer to the “User’s Manual (Software Guide (1) & (2)) (MANUAL Nos. 99MCA082 &
99MCA083)” for information on the data processing functions.
No. 99MCA081A
5-1
