Mitutoyo QM-Data 300 - Foot Switch

3. BASIC OPERATIONS
TIP
• The communication conditions (namely, baud rate, word length, parity check, stop bit)
were set when the unit shipped.
3.3.4 Foot Switch
Insert the foot switch plug into the foot switch input jack (FS jack) on the rear of the
data processing unit.
If you step on the foot switch during a measurement, the measured data at that time
will be input to the data processing unit.
No. 99MCA081A
3-7
