1. INTRODUCTION
(1) LCD
The LCD (Liquid Crystal Display) displays measurement result.
(2) Suspend key
When the data processing unit “QM-Data” is in Suspend Mode, the LED
corresponding to this Suspend key lights. If this key is pressed in Suspend Mode, then
the system starts up in the state prior to Suspend Mode. The measured data, obtained
before the Suspend Mode was entered, is retained.
When the data processing unit will not be used for some time, for example
during lunch, activate the Suspend Mode to reduce the power consumed by the data
processing unit.
Unlike when the power switch is OFF, a small amount of electricity is used in
Suspend Mode. Consequently, if you do not intend to use the data processing unit for
a long time, for example over a holiday, turn off the power switch on the data
processing unit.
(3) DC jack
This is a jack used to connect the AC adapter which is a standard accessory.
(4) Power switch
Setting the power switch knob to the “|” position turns the power ON; and setting
the power switch knob to the “O” position turns the power OFF.
When electric power is supplied from the AC adapter, the built-in green LED
lights.
When you turn off the power switch, internal setting will be retained, but
measured data that has not been stored will be lost.
(5) Key panel
From this key panel, you can create various settings and perform input. This key
panel includes the measurement command keys.
(6) Back cover
Do not open the back cover. The back cover is for maintenance.
(7) Printer connector (PRINTER connector)
This is a connector for connecting the printer.
(8) CMM connector (CMM connector)
This is a connector for connecting the CMM (Coordinate Measuring Machine).
No. 99MCA081A
1-3
