Setting up the unit
22 Installation instructions
5.2 Lifting the unit off the pallet
CAUTION
Risk of property damage and personnel injury from tipping
equipment
• Do not linger next to or behind raised equipment.
• Move raised equipment carefully.
ATTENTION
Risk of physical damage from lifting the unit incorrectly
• Place the forks of the lift truck next to the waste trap.
Requirement Unit unpacked
Protective film removed
Unit cleaned
Image: Lifting the unit off the pallet
1. Slide the forks of the pallet truck under the unit and to the right of
the waste trap.
2. Lift the unit off the pallet.
5.3 Setting up the unit on the equipment legs
Requirement The floor must carry the weight of the unit
1. Lift the unit with the pallet truck.
2. Move the unit to the installation site.
3. Place the unit on the floor.
4. Set up the unit in accordance with the planning drawing (see
"Planning drawing").
10013865-0AIBE-B
