Connecting the unit
26 Installation instructions
6 Connecting the unit
DANGER
Risk of personal injury and physical damage from electric
shock
• Prior to working on the unit, ensure that the unit has been
disconnected from the mains.
• Do not operate the unit with the housing open.
CAUTION
Risk of injury from sharp edges
• Wear protective gloves.
ATTENTION
Risk of physical damage from damage to the lines
• Remove and attach housing components carefully.
6.1 Opening and closing the housing
6.1.1 Removing and attaching side wall
Removing the side wall
Image: A Size 6XX and 1XX; B Size 2XX
1. Unscrew the screws on the side wall.
2. Pull the bottom edge of the side wall forwards.
3. Remove the side wall.
10013865-0AIBE-B
