MKN FlexiCombi MagicPilot FKECOD615 - Equipment and connection data

Description of the unit
13Installation instructions
3.3 Equipment and connection data
Model: FKECOD
Size 615 621 115 121 215 221
Dimensions
Unit
Length x Width x Height (mm)
997 x 799 x 790 997 x 799 x 1060 1075 x 813 x 1960
Weight
(kg) unit 120 125 140 145 305 313
Emissions
Latent heat (W) 1780* 3670* 2750* 5400* 5510* 10200
Sensible heat (W) 1190 2450 1840 3600 3670 7100
Noise level (db(A)) < 70
* The stated value is reduced by 80% when operating with a condensation hood; the sensible heat is increased by the
amount of the reduction.
Operating environment
Temperature (°C) 5 — 40
Relative humidity (%)
Non-condensing
95
Power connection
Protection class IPX5, IPX6 (optional)
Type of connection 3PE / AC 50/60Hz, 3NPE / AC 50/60Hz
Voltage (V) 200
Connected load (kW) 10.1 16.3 14.7 25.5 29.4 50.9
Fuse (A) 3 x 35 3 x 50 3 x 50 3 x 80 3 x 100 3 x 180
Voltage (V) 208
Connected load (kW) 10.2 17.4 15.7 27.3 31.4 54.6
Fuse (A) 3 x 35 3 x 50 3 x 50 3 x 80 3 x 100 3 x 180
Voltage (V) 220
Connected load (kW) 11.6 19.7 17.7 30.8 35.4 61.4
Fuse (A) 3 x 35 3 x 63 3 x 63 3 x 100 3 x 125 3 x 180
Voltage (V) 230
Connected load (kW) 12.6 21.4 19.3 33.6 38.6 67
Fuse (A) 3 x 35 3 x 63 3 x 63 3 x 100 3 x 125 3 x 180
Voltage (V) 240
Connected load (kW) 13.7 23.3 21 36.5 42 72.9
Fuse (A) 3 x 35 3 x 63 3 x 63 3 x 100 3 x 125 3 x 180
Voltage (V) 380
Connected load (kW) 9.4 18.9 14.4 27.6 28.7 55
Fuse (A) 3 x 16 3 x 35 3 x 25 3 x 50 3 x 50 3 x 100
10013865-0AIBE-B
