SECTION 2: TOOLS AND SUPPLIES REQUIRED
The tools and supplies listed below will be necessary to finish the final assembly of your Dragon Lady 60 ARF. We suggest
having these items on-hand before beginning assembly.
We have organized the parts as they come out of the box for easier identification during assembly. Before you begin
assembly, group the parts as we list them below. This will ensure that you have all of the parts before you begin assembly
and it will also help you become familiar with each part. If you find any parts missing or damaged, please contact us using
the information below:
AIRFRAME ASSEMBLIES
(1) Fuselage
(1) Right Wing Panel w/Aileron
(1) Left Wing Panel w/Aileron
(1) Horizontal Stabilizer w/Elevator
(1) Vertical Stabilizer w/Rudder
SECTION 3: KIT CONTENTS
AILERON CONTROL SYSTEM
(1) Plywood Aileron Servo Tray (W22)
(2) 4-1/2" Threaded Wires w/90º Bend
(2) Nylon Adjustable Control Horns
(2) Nylon Clevises
(2) Nylon 90º Snap Keepers
(8) C/A Style Hinges
Continued On Next Page
THROTTLE CONTROL SYSTEM
(1) 18-3/8" Pushrod Wire w/Z-Bend
(1) Adjustable Servo Connector Assembly
Global Services
18480 Bandilier Circle
Fountain Valley CA 92708
Phone: (714) 963-0329 Fax: (714) 964-6236 E-mail: service@globalhobby.net
