LANDING GEAR ASSEMBLY
❑ (1) Prebent Aluminum Main Gear Strut
❑ (2) Blow-Molded Wheel Pants
❑ (2) Main Gear Wheels
❑ (2) Plywood Mounting Plates (D36)
❑ (2) 4mm Threaded Axles w/Lock Nuts
❑ (4) 4mm Wheel Collars w/Set Screws
❑ (4) 4mm x 20mm Machine Screws
❑ (4) 4mm Flat Washers
❑ (2) 3mm x 12mm Machine Screws
❑ (2) 3mm Blind Nuts
ELEVATOR CONTROL SYSTEM
❑ (1) 31" Threaded Wire
❑ (1) Nylon Control Horn w/Backplate
❑ (2) 2mm x 20mm Machine Screws
❑ (1) Nylon Clevis
❑ (1) Nylon 90º Snap Keeper
❑ (6) C/A Style Hinges
RUDDER CONTROL SYSTEM
❑ (1) 31" Threaded Wire
❑ (1) Nylon Control Horn w/Backplate
❑ (2) 2mm x 20mm Machine Screws
❑ (1) Nylon Clevis
❑ (1) Nylon 90º Snap Keeper
❑ (3) C/A Style Hinges
MISCELLANEOUS WING PARTS
❑ (1) Hardwood Wing Joiner (W3)
❑ (2) 5mm x 40mm Machine Screws
❑ (2) 5mm Flat Washers
❑ (2) 5mm Blind Nuts - Optional
MISCELLANEOUS FUSELAGE PARTS
❑ (1) Prepainted Fiberglass Cowling
❑ (1) Plywood Engine Mount Spacer (F1A) - Optional
❑ (1) Plywood Fuselage Servo Tray (D29)
❑ (1) Clear Plastic Windscreen
❑ (4) 3mm x 10mm Wood Screws
❑ (4) 3mm Flat Washers
❑ (2) 2mm x 6mm Wood Screws
❑ (1) Length of Clear Tubing
❑ (1) Decal Sheet
FUEL TANK ASSEMBLY
❑ (1) 360cc Fuel Tank
❑ (1) Large Diameter Metal Plate
❑ (1) Small Diameter Metal Plate
❑ (1) Rubber Stopper
❑ (1) Fuel Pick-Up "Clunk"
❑ (1) 3mm x 20mm Machine Screw
❑ (1) Silicon Fuel Tubing
❑ (2) Aluminum Tubing
ENGINE MOUNT ASSEMBLY
❑ (2) Engine Mounting Beams
❑ (4) 4mm x 20mm Socket-Cap Screws
❑ (4) 4mm x 30mm Socket-Cap Screws - Optional
❑ (4) 4mm Blind Nuts
❑ (4) 4mm x 25mm Socket-Cap Screws
❑ (4) 4mm Lock Nuts
❑ (12) 4mm Flat Washers
TAIL WHEEL ASSEMBLY
❑ (1) Nylon Tail Wheel Bracket
❑ (1) Nylon Tail Wheel Tiller Arm
❑ (1) Prebent Tail Wheel Wire
❑ (1) Tail Wheel
❑ (2) Wheel Collars w/Set Screws
❑ (1) Nylon Spacer
❑ (1) 2.5mm x 12mm Wood Screw
❑ (3) 3mm x 12mm Wood Screws
To convert inches into millimeters: Inches x 25.4 = mm To convert millimeters into inches: Millimeters / 25.4 = in
1/64" = .4mm
1/32" = .8mm
1/16" = 1.6mm
3/32" = 2.4mm
1/8" = 3.2mm
5/32" = 4.0mm
3/16" = 4.8mm
1/4" = 6.4mm
3/8" = 9.5mm
1/2" = 12.7mm
5/8" = 15.9mm
3/4" = 19.0mm
1" = 25.4mm
2" = 50.8mm
3" = 76.2mm
6" = 152.4mm
12" = 304.8mm
18" = 457.2mm
21" = 533.4mm
24" = 609.6mm
30" = 762.0mm
36" = 914.4mm
SECTION 4: METRIC CONVERSION CHART
