Connections
17
04/99 AWB 2700-1311 GB
Overview
Figure 4: Overview of the connections
햲
Screw terminals: 24 V DC power supply
Connector cross-sections:
flexible with ferrule 0.22 to 2.5 mm
2
(AWG 23 ... 13)
solid 0.22 to 2.5 mm
2
(AWG 23 ... 13)
햳
Plug-in screw terminals
햴
Conductor cross-sections:
flexible with ferrule 0.22 to 1.5 mm
2
(AWG 23 ... 16)
solid 0.22 to 2.5 mm
2
(AWG 23 ... 13)
햵
Plug connector for local expansion modules (LE 4)
햶
Suconet K interface (RS 485)
햷
Programming device interface (RS 232)
Suconet K
1
2
Power Supply
PRG
햳
햴
햳
햴
햳
햴
햲
햶
햷
햳
햴
+
햵
