Moeller PS 4-341-MM1 - Page 34

Engineering
32
04/99 AWB 2700-1311 GB
Figure 14: Using separate ducts for power and signal
cables
햲 Cover
햳 Communication cables
햴 Cable duct
햵 Measuring cables,
analog cables
햶 Control cables
햷 Power cables
햸 Continuous partition
햳
햶
햷
햲
햴
햵
햷
햲
햳 햵 햶
햸
