Configuring stations
39
04/99 AWB 2700-1311 GB
Figure 17: Double configuration of a slave with CPU
341-MM1-4 SP LE 4 LE 4 LE 4
PS 4-201-MM1
LE 4-501-BS1 LE 4
EM 4
Master configuration
Slave configuration
Master/Slave configuration
