Technical data
89
04/99 AWB 2700-1311 GB
Short-circuit release current Max. 1.2 A over 3 ms per output
Off delay Typically 100 µs
Limiting of the breaking voltage
for inductive loads Yes, –21 V (at U
N
= 24 V DC)
Switching rate per hour
For time constant
t ≤ 72 ms
4800 (G = 1)
7500 (G = 0.5)
For time constant
t ≤ 15 ms
18,000 (G = 1)
Power supply
Polarity reversal protection Yes
Admissible range 20.4 to 28.8 V DC
Max. residual ripple ≤ 5 %
Status display for outputs Yes (LEDs)
Terminals Plug-in screw terminals
Conductor cross-sections
Flexible with ferrule 0.22 to 1.5 mm
2
Solid 0.22 to 2.5 mm
2
Analog outputs
Number 1
Bit resolution 12 (4096 units)
Total error Typically 0.4 % of full scale
Output variables 0 to 10 V DC/2 mA
Connection type Two-wire connection
H1311g.bk Seite 89 Freitag, 4. Juni 1999 1:12 13
