HarshIO 600 eIP
32
IP67 Digital I/O Modules for EtherNet/IP
12 Inputs + 4 Outputs module versions
Byte
Offset
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Input Data (Assembly #103), Size: 8 bytes
Data
00
n/u
n/u
n/u
n/u
n/u
n/u
Diag
UB
n/u
Diag
UL
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Input Data
02
n/u
n/u
n/u
n/u
I11
I10
I9
I8
I7
I6
I5
I4
I3
I2
I1
I0
Port Status
04
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Port Status
06
n/u
n/u
n/u
n/u
CS O3
CS O2
CS O1
CS O0
n/u
n/u
PS P5
PS P4
PS P3
PS P2
PS P1
PS P0
Output data (Assembly #104), Size: 4 bytes
00
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Output Data
02
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
O3
O2
O1
O0
Configuration (Assembly #106), Size: 16 bytes
Data
00
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
02
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
04
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
06
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
08
n/u
n/u
n/u
n/u
n/u
n/u
n/u
QC
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
10
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
12
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
Data
14
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u
n/u: Not used
Ix: Input channel x
Ox: Output channel x
PS: Input Port Status (short circuit on Input channel)
CS: Channel status (short circuit on Output channel or impossible to drive the Output)
If output power supply (UL) is down, output channel status (CS) is set for the corresponding activated
output channels. The module display shows the message:”IO: ERR”.
Example: if the output “O3” is active and UL goes down, the “CS O3” status bit is set to 1.
QC: Quick Connect, 1 = Enable; 0 = Disable
Diag UB: Diagnostic Logic/Input power supply (UB)
Set to 1, if UB is < 14.1 VDC
o All Outputs activated are de-energized
o All Outputs activated have diagnostic leds to RED
o All Outputs activated have Port Status (CS Ox) bit set to 1
Set to 0, if UB is > 14.6 VDC
o All Outputs activated are energized
o All Outputs activated have diagnostic leds to GREEN
o All Outputs activated have Port Status (CS Ox) bit set to 0
