IP67 Digital I/O Modules for EtherNet/IP
Network IP address setting
The HarshIO 600 eIP is configured in DHCP mode by default. When connecting to a network with a DHCP
server, an IP address is automatically assigned to the module.
You can stop the DHCP procedure (in case of no DHCP server on the network) by touching the push-buttons
located in the Window area of the module .
The Factory default IP Address is 192.168.1.1
To change or set the default IP address, the operator has the possibility to use one of the following methods:
1. Use of the display
Use the push-buttons and the scrolling display; This method only allows an operator to change the
last byte of the IP address (192.168.1.x). To change the network IP address, push on the right or left
button of the clear window of the HarshIO module.
o Right button behavior (clockwise) :
o Left button behavior (counterclockwise) :
Note: When IP address is selected, it will be stored in non-volatile memory after 5 seconds of inactivity
on the push-button. The IP address will be taken in account after a module reset or a power cycle.
During this phase, a message “NEED RESET” is showed on the display of the module.
Note: When changing DHCP mode into Static IP mode, the mask of the Static IP address
(xxx.xxx.xxx.) will be the same as it was in DHCP mode (given by the DHCP server).
