HarshIO 600 eIP

18

IP67 Digital I/O Modules for EtherNet/IP
4. Module Characteristics
Hardware characteristics
Type
16x INPUTS
16x OUTPUTS
Product Reference
TCDEI-8D0P-DYU-G (4-pin power version)
TCDEI-8D0P-D1U-G (5-pin power version)
TCDEI-80DP-DYU-G (4-pin power version)
TCDEI-80DP-D1U-G (5-pin power version)
Power
Power IN connector
Mini Change (7/8”), 4-pin or 5-pin, male, stainless steel, Maximum 8 A
Power OUT connector
Mini Change (7/8”), 4-pin or 5-pin, female, stainless steel, Maximum 8 A
Module & Input power (UB)
24 VDC, -15/+20% (protected against power crossing).
Warning, a voltage over 30 VDC will destroy the module
Operating current (UB)
68 mA
Output power (UL)
Not Applicable
24 VDC, -15/+20%
(protected against power crossing)
Operating current (UL)
Not Applicable
10 mA (without load)
Inputs
Channels
16 channels, 2 or 3-wire
Not Applicable
Connector
M12 Ultra-Lock, 5-pin, female, A-Coded,
stainless steel
Not Applicable
Input type
PNP, Sinking
Not Applicable
Input voltage
UB
Not Applicable
Sensor power supply
140 mA at 25°C
Not Applicable
Input channel voltage (“1”)
10V … 30V
Not Applicable
Input channel voltage (“0”)
-0.2V … 5V
Not Applicable
Input short circuit
protection (per port)
600mA
Not Applicable
Input filter
1 … 5 ms (5 ms by default)
Not Applicable
Outputs
Channels
Not Applicable
16 channels, 2-wire
Output voltage
Not Applicable
UL -1 VDC
Connector
Not Applicable
M12 Ultra-Lock, 5-pin, female, A-Coded,
stainless steel
Output type
Not Applicable
PNP, Sourcing
Output current
Not Applicable
2 A per channel
Maximum output current
Not Applicable
8.0 A at 25°C ; total for all outputs combined
Short circuit current (typical)
Not Applicable
up to 6.5 A
Switching frequency
Not Applicable
200 Hz
