HarshIO 600 eIP

46

IP67 Digital I/O Modules for EtherNet/IP
Hardware address (MAC Address)
Each HarshIO 600 eIP has a unique Ethernet MAC address figured on the attached label on the back of the
module. This address has a fixed length of 6 bytes (48 bits) including the manufacturer’s ID and the serial
number of the HarshIO module.
The MAC address will be defined as the following:
Manufacturer ID
Family
Serial Number
00.A0.91
3
X.XX.XX
EDS files
The EDS files can be downloaded from the Molex website:
http://www.molex.com/molex/mysst/DownloadCenter.action
Configure the HarshIO 600 eIP via the EDS file. In this EDS file, the HarshIO 600 eIP is implemented as
standard device in your system.
EDS file list for HarshIO 600 eIP devices:
4-pin power supply versions
Name
EDS File
Product
Code
TCDEI-8D0P-DYU-G
0008000C03200601.eds
0x320
TCDEI-888P-DYU-G
0008000C03230601.eds
0x323
TCDEI-8B4P-DYU-G
0008000C03220601.eds
0x322
TCDEI-80DP-DYU-G
0008000C03290601.eds
0x329
5-pin power supply versions
Name
EDS File
Product
Code
TCDEI-8D0P-D1U-G
0008000C03400601.eds
0x0340
TCDEI-8B4P-D1U-G
0008000C03420601.eds
0x0342
TCDEI-888P-D1U-G
0008000C03430601.eds
0x0343
TCDEI-80DP-D1U-G
0008000C03490601.eds
0x0349
