molex BradControl HarshIO 600 eIP - 7 Getting Started; Packaging Content; Accessories

HarshIO 600 eIP

54

IP67 Digital I/O Modules for EtherNet/IP
7. Getting Started
Packaging content
Each product packaging includes:
 1x HarshIO 600 eIP module
 9x plastic labels (for digital channel labeling)
 8x M12 male closure caps (for sealing unused port)
Accessories
Required devices, accessories and cordsets:
Reference
Description
Quantity
Manufacturer
Devices
Programmable controller processor with
EtherNet/IP scanner port
1
TCDEI-8D0P-DYU-G
TCDEI-888P-DYU-G
TCDEI-8B4P-DYU-G
TCDEI-80DP-DYU-G
TCDEI-8D0P-D1U-G
TCDEI-888P-D1U-G
TCDEI-8B4P-D1U-G
TCDEI-80DP-D1U-G
HarshIO 600 eIP
N
BradControl from Molex
Network communication
EWWA06003Mxy0*
+
ER1PADAPTER
From Scanner to HarshIO module
M12 Ultra-Lock™ (male D-coded) straight
double-ended cordsets + M12-to-RJ45
bulkhead adapter
1
BradControl from Molex
EWWA06003Mxy0*
For HarshIO module network chaining
M12 Ultra-Lock™ (male D-coded) straight
double-ended cordsets
N-1
BradControl from Molex
Power supply
-
24 VDC Power supply
1
-
104006A01Mxy0*
From Power supply module to HarshIO
module
Mini-Change
©
4-pole female straight
single-ended cordsets
1
BradControl from Molex
114030A01Mxy0*
For HarshIO module power chaining
Mini-Change
©
4-pole female straight / Mini-
Change 4-pole male straight double-ended
cordsets
N-1
BradControl from Molex
Inputs / Outputs
-
Field device (actuator or sensor)
N*16
(max.)
-
M12 Ultra-Lock™ (male A-coded) straight
single-ended cordsets
N*8
BradControl from Molex
(*) xy represents the length of the cordsets in meter (M). For instance, “05” indicates a cordset of 5M.
Available lengths 1M, 2M, 3M, 4M, 5M or 10M according to cordset reference (see Cables and Cordsets).
