IP67 Digital I/O Modules for EtherNet/IP
Diag UL: Diagnostic Output power supply (UL)
Set to 1, if UL is < 17.6 VDC
o All Outputs activated are de-energized
o All Outputs activated have diagnostic leds to RED
o All Outputs activated have Port Status (CS Ox) bit set to 1
Set to 0, if UL is > 18.1 VDC
o All Outputs activated are energized
o All Outputs activated have diagnostic leds to GREEN
o All Outputs activated have Port Status (CS Ox) bit set to 0
