User Reference Guide SST-PB3S-CLX-RLL
22 Installing the SST-PB3S-CLX-RLL Slave
©2014 Molex Inc. Industrial Products Business Unit, Integrated Products Division
Document Edition: 1.0, Document #: 715-0109, Template Edition: 1.1, Template #: QMS-06-045
Use, duplication or disclosure of this document or any of the information contained herein is subject to the restrictions on page ii of this document.
4.1 Installing the Slave Module
4.1.1 Installation Procedure
The following procedure describes how to install the slave module:
Warning
If installing the module while the chassis is powered up, make sure the
environment is free of explosive or hazardous dusts or gases. If there is a
possibility of gases present, remove the hazardous dusts or gases, and
power down the chassis before installing the module. Serious injury or
damage to equipment may result if this warning is not followed.
1. You can, but do not necessarily need to disconnect the power, as the slave supports insertion
under power. Read and follow the Warning described above.
2. Using the chassis card guides, align the full-sized circuit board.
3. Slide the module into the chassis until the top and bottom latches catch.
4. Attach the PROFIBUS cable.
5. Turn on connector termination as required.
6. Route the cable down and away from the slave.
4.1.2 Removal Procedure
The following procedure describes how to uninstall the slave module:
Warning
If removing the module while the chassis is powered up, make sure the
environment is free of explosive or hazardous dusts or gases. If there is a
possibility of gases present, remove the hazardous dusts or gases, and
power down the chassis before removing the module. Serious injury or
damage to equipment may result if this warning is not followed.
1. You can, but do not necessarily need to disconnect the power, as the slave supports removal
under power. Read and follow the Warning described above.
2. Remove all cabling from the slave.
3. Press releases at the top and bottom of the module and slide the module out of the slot.
