4.3 PROFIBUS LED and Display States
The following tables show how the LEDs and the display work together to provide detailed
information on the operation of the slave.
Table 4: COM LED Behavior
LED State
Description
Solid Red
A recoverable or unrecoverable fatal error has occurred when COMM
and SYS LED are solid red at the same time.
Off
The Profibus slave is in offline or online state.
Flashing RED
This may occur when putting the Profibus Slave online but the COMM
LED should then go off and remain off after going online.
Table 5: OK LED Behavior
LED State
Description
Solid Green
Initialization is complete and module is ready
Solid Red
Hardware error
Table 6: SYS LED Behavior
LED State
Description
Solid Green
The Profibus slave is being scanned by a DP Master in RUN mode.
Solid Red
The Profibus slave is online but is not being scanned by a DP Master
Amber
The Profibus slave is online and being scanned by a DP Master in
CLEAR mode.
Off
The Profibus slave is offline.
Note
The COMM LED is always off while the slave is operational.
