A.1 Technical Specifications
Table 23: Technical Specifications for the SST-PB3S-CLX-RLL, SST-PB3S-CLX-RLL-CC,
SST-PB3S-CLXT-RLL modules
Part Number
SST-PB3S-CLX-RLL, SST-PB3S-CLX-RLL-CC, SST-PB3S-CLXT-RLL
Function
CLX-5000 slave for PROFIBUS networks
Description
• Freescale MCF5272 processor
• 8 MB of MCF5272 local RAM
• 512 KB of onboard shared memory
• 512 KB of sectored flash memory for storage of program and configuration data
• ASPC2 LAN controller
CLX Interface
SST-PB3S-CLX-RLL supports up to a 122 words of input data and 122 words of
output data. Status information available..Supports up to 244 bytes total data
exchange
250 words Status
Environmental
Storage temperature -40°C to 85°C
Operating temperature:
0°C to 60°C SST-PB3S-CLX-RLL
0°C to 60°C SST-PB3S-CLX-RLL-CC
-25°C to 75°C SST-PB3S-CLXT-RLL
Operating RH level 5% to 95%, non-condensing
Pollution Degree 1 - no pollution or only non-conductive or non-corrosive pollution
Backplane
Current
Consumption
850 mA @ 5 VDC 1.75 mA@24 VDC
