4.2.1 Selecting the Proper Line Type
Use this table to determine which line type best suits your system requirements.
Table 3: Line Types
Baud Rate (Bits/s) Line A Distance (Max) Line B Distance (Max) Register Value
9k6, 19.2k, 45.45 k and
93.75k
1200 m** 1200 m** 0, 1, 11, 2
187.5k 1000 m** 600 m** 3
500k 400 m** 200 m** 4
1.5M 200 m** NA 6
3, 6 and 12M 100 m** NA 7, 8, 9
NA = Not Applicable
*If using a combination of both line types, divide the lengths shown by two.
**This is the sum of all bus segment and drop cable lengths.
Note
The two physical ends of the PROFIBUS network should be terminated.
There should be only two terminators on a network.
