102 • Section 4 — Appliances Cayman 2006
Icemaker (Optional)
The icemaker requires 120 Volts AC to operate. Only after
the freezer reaches freezing temperature will the icemaker
function. City water or the water pump must be on and the valve
for the water supply line to the icemaker must be on.
• Pull the metal arm (bail) down to turn the icemaker ON.
• Push the arm up to turn the icemaker OFF.
NOTE:
Water may spill out of the ice tray when the icemaker is in operation while the motorhome
is in motion. Raise the icemaker arm to stop ice production while in transit. DO NOT
use the first one or two trays of ice if the refrigerator has been in storage. Ice cubes may
have contaminates. DO NOT operate the icemaker without water pressure supplied to the
refrigerator as this can damage the icemaker assembly.
Water Line Heater:
A thermal disc supplies voltage
to heater tape when ambient
temperature is less then 38° F
(+/- 4°) and shuts off at temperature
greater than 48° F (+/- 5°). The
water line heater is only for the line
from the solenoid to the icemaker.
The line from the icemaker shut-
off valve to the water valve is not
protected.
Refrigerator Alarm
The refrigerator uses an audible alarm that will sound for the following reasons:
1. DC or AC voltage is higher or lower than allowed.
2. Refrigerator is set to Auto, 120 Volts AC is discontinued and LP Gas fails to light.
3. The refrigerator fails to light on LP-Gas or fails to light after a period of operation.
4. Door is open longer than two minutes.
5. The circuit board detects a failure. The control panel will display a code.
NOTE:
If the alarm sounds, note the code in the LED display and turn the refrigerator off to silence
the alarm.
INFORMATION:
Refer to the manufacturer’s manual for the list of codes and their meanings.
031007
030974d
Thermal
Disc
